25mm Full Color Resolution

(25)mm Full Color units are the most economical LED display resolution. When using (25)mm resolution displays we recommend using only text based messages.

We recommend using this type of display to advertise: Date, Time, Sales Promotions, Directions,
Public Service Announcement ect. (25)mm Full Color displays will however, produce videos and
graphics in shades of color in the event you want to use this type of advertisement.

(25)mm 2 Red, 1 Green and 1 Blue- SIGN SPEC SHEET

SIGN FEATURES	WIRELESS COMMUNICATION

Sign Certification	(ETL) Certified	Wireless Type	Radio Frequency
Viewing Angle	160º	Wireless Range	(2) Miles
Brightness	10,000 NITS	Connectivity	Line of Sight
LED Life Expectancy	100,000 Hours	Frequency Consumption	5(ghz)
Working Temperature	(-20º) to 170º	Bandwidth Capacity	300 (mbps)
Pixel Type	True (Not Virtual)	Antenna Type	Bi Directional
IP Code	IP 65 Rating	Internal Antenna	13 (dbi)

CABINET SPECIFICATIONS	SERVICES PROVIDED

Cabinet Weight	Based on Size	Technical Support	Unlimited
Cabinet Boarder	2" Boarder (Perimeter)	Software Upgrades	For the Life of the Account
Module Service	Front Service	Content Program	Artistry Creation(7)
Cabinet Make Up	Steel Construction	Warranty Coverage	Total Parts Replacement
Mounting Brackets	Standard 2" angle (Back)	Warranty Duration	(5) Year Warranty
Cabinet Protection	Power Coated	Software Platform	Windows 7
Exhaust Location	Back Side of Cabinet	Technology Type	Plug and Play
